High Pressure 1/8″ and 1/4″ Brass Pipe fittings and the like.
(Pipe to pipe)     (Pipe to JIC-4)     (SAE to JIC-4)



Inserts and SCD’s

5IHDW 0300 00 Rev 2 [5SHDW 0300 00] (HP NPT Pipe Fittings (SCD)
Size : 91.4 kB Format : PDF

5IHDW 0500 00 Rev 3 [5SHDW 0500 00$ 3](HP Adapter Fittings SCD)
Size : 474.1 kB Format : PDF


Pipe-JIC-SAE Fittings

ImageSKUNameSummaryPriceBuy
00HDW-0300-00Union 1/4 NPT-M To 1/4 NPT-M, Brass

Brass Union 1/4″ NPT-M to 1/4″ NPT-M

$10.00
00HDW-0302-00Union 1/8 NPT-M To 1/8 NPT-M, Brass

Brass Union 1/8″ NPT-M to 1/8″ NPT-M

$8.50
00HDW-0304-00Union 1/4 NPT-F to 1/4 NPT-F, Brass

Brass Union 1/4″ NPT-F to 1/4″ NPT-F

$15.00
00HDW-0306-00Union 1/8 NPT-F, Brass

Brass Union 1/8″ NPT-F to 1/8″ NPT-F

$9.00
00HDW-0308-00Union Reducing 1/4 NPT-F to 1/8 NPT-F, Brass

Brass Reducing Union 1/4″ NPT-F to 1/8″ NPT-F

$19.50
00HDW-0314-00Union Reducing 1/4 NPT-M To 1/8 NPT-F, Brass

Brass Reducing Union 1/4″ NPT-M to 1/8″ NPT-F

$6.00
00HDW-0316-00Elbow 1/4 NPT-M to 1/4 NPT-M, Brass

Brass Elbow 1/4″ NPT-M to 1/4″ NPT-M

$24.00
00HDW-0318-00Elbow 1/8 NPT-M to 1/8 NPT-M, Brass

Brass Elbow 1/8″ NPT-M to 1/8″ NPT-M

$15.00
00HDW-0320-00Elbow 1/4 NPT-F to 1/4 NPT-F, Brass

Brass Elbow 1/4″ NPT-F to 1/4″ NPT-F

$35.00
00HDW-0322-00Elbow 1/8 NPT-F to 1/8 NPT-F, Brass

Brass Elbow 1/8″ NPT-F to 1/8″ NPT-F

$14.00
00HDW-0324-00Elbow 1/4 NPT-M to F, Brass

Brass Elbow 1/4″ NPT-M to 1/4″ NPT-F

$21.00
00HDW-0326-00Elbow 1/8 NPT-M To 1/8 NPT-F, Brass

Brass Elbow 1/8″ NPT-M to 1/8″ NPT-F

$18.00
00HDW-0329-001/4 NPT-M to 1/8-F Reducing Elbow

1/4 NPT-M to 1/8-F Redu. Elbow

$25.00
00HDW-0332-00Union Tee 1/4 NPT-F, Brass

Brass Union Tee 1/4″ NPT-F

$25.00
00HDW-0334-00Tee Run 1/4 NPT, Brass

Brass 1/4″ NPT Street Tee

$45.00
00HDW-0336-001/4 NPT-M Tee Brass

1/4 NPT-M tee brass

$12.00
00HDW-0338-001/4 Branch Tee, Brass

1/4 Branch Tee, Brass

$15.00
00HDW-0340-00Union Tee 1/8 NPT-F, Brass

Brass Union Tee 1/8″ NPT-F

$24.00
00HDW-0342-00Tee Run 1/8 NPT, Brass

Brass Street Tee 1/8″ NPT

$48.75
00HDW-0346-00Tee Branch 1/8 NPT, Brass

Brass Branch Tee 1/8″ NPT

$39.00
00HDW-0348-00Cross 1/4 NPT-F, Brass

Brass Cross 1/4″ NPT-F

$29.50
00HDW-0350-00Cross 1/8 NPT-F, Brass

Brass Cross 1/8″ NPT-F

$17.00
00HDW-0351-001/8 NPT-F Bulkhead .99, Brass

Brass 1/8″ NPT-F Bulkhead .99 Fitting

$25.00
00HDW-0352-00Union 1/8 NPT-M to F, Brass

Brass Union 1/8″ NPT-M to 1/8″ NPT-F

$13.95
00HDW-0355-001/4 NPT-F Bulkhead .99, Brass

Brass 1/4″ NPT-F Bulkhead .99 Fitting

$10.00
00HDW-0113-00JIC-4 (M)-1/8NPT(F), Brass

Brass 4 JIC-M to 1/8″ NPT-F Compression Fitting.

$13.50
00HDW-0319-00JIC-4 (M) to 1/4 NPT-M, Brass

Brass 1/4″ NPT-M to -4 JIC-M

$8.50
00HDW-0321-00JIC-4 (M) to 1/8 NPT-M, Union Brass

Brass Union -4 JIC-M to 1/8″ NPT-M

$7.50
00HDW-0202-00JIC-4 (M) to 1/8 NPT-M Brass Tee

Brass Union Tee -4 JIC to  1/8″ NPT-M

$49.95
00HDW-0317-00JIC-4 (M) to 1/4 NPT-F, Brass

Brass -4 JIC-M to 1/4″ NPT-F

$18.00
00HDW-1382-00JIC-4 (M) to 1/8 BSPP, Steel

1/8″ BSPP to JIC-4 Flare Steel Fitting.

$8.95
00HDW-0315-00SAE-4 (F) to 1/8 NPT-M, Brass

Brass Adaptor 1/8″ NPT-M to -4 SAE-F

$45.00
00HDW-1381-01SAE-4 (M) to JIC-4 Flare, SS

SAE-4 (M) to JIC-4 Flare SS Fitting.

$18.00
00HDW-0113-05SAE-4 (M) to 1/8" NPT-F, Brass

SAE-4M to 1/8 NPT-F, Brass (with O-Ring)

$9.45
00HDW-1381-02SAE-4 (M) to JIC-4 Flare, Steel

SAE-4 (M) to JIC-4 Flare Steel Fitting.

$5.00
00HDW-1383-02SAE-4 (M) to JIC-4, 90', Steel

SAE-4 to JIC-4  90′ Steel Fitting.

$18.00
