EDS-O2D2-2G Pulse Demand™ System

Basic Kits with Reg
Kits For Built-In Oxygen Sys
Kits With Aluminum Cyl
Kits With Composite Cyl




AVAILABLE NOW!



Mountain High Oxygen is pleased to announce the release of our next generation of EDS (Electronic Delivery System) Pulse Demand oxygen controllers, the O2D1-2G and O2D2-2G.



These changes are common to both the O2D1 and O2D2 family of EDS.

Our new Pulse Demand systems still incorporate all of the benefits of our legacy controllers but with many improvements. Like the series of the old VW Beetle, it's the same, but better.

We started with the control switch: The EDS unit now incorporates a MIL spec ruggedized easy-to- grip rotary control switch providing improved reliability, increased ease of function and visibility. This switch also has very positive position detents for excellent tactile feedback making it resistant to changes from causal rubbing or bumping.

While we were at it, we improved the manifold design to allow for better breathing response and effort tracking. This combined with a new circuit board, as well as a new micro-controller, gives improved power-conserving operations with even less RFI emissions, better respire-metric tracking and dispensing of oxygen in finer resolution resulting in smoother steps from altitude and breathing changes.

Other improvements include a dedicated bi-color system battery status light allowing much easier monitoring and definitive indication of battery condition without being confused as a station operation. The original O2Dx units encoded the low battery notification into the station lights. This status light also responds to each control switch change with a beep and green flash to confirm your actions. Also the audio alerts and warnings are louder, more crisp and dynamic to human hearing in an effort of being heard over modest cabin noise. The O2D2 has a 600 Ohm stereo external audio jack as well as a USB compatible (5VDC) external power port.

More intuitive F-Mode settings labeled as 1, 2, 3 & 4 for use with face masks or when more oxygen is required.



How Pulse Demand Works



The patented MH EDS (Electronic Delivery System) is a one (O2D1-2G)  or two-user (O2D2-2G) aviation oxygen delivery device. It is designed to deliver aviation oxygen in the most efficient, comfortable and convenient way possible. With its user-selectable settings, apnea alarm and small size, the MH EDS  is the most portable and flexible electronic digital oxygen delivery system in the world. By providing a measured pulse of oxygen every time you breathe in, the MH EDS supplies the oxygen you need to stay alert and comfortable while flying. In contrast to constant flow systems that waste oxygen by supplying more than your body can use, the MH EDS provides a short pulse of oxygen as you inhale, ensuring that your oxygen is used most efficiently. Efficient oxygen delivery means you can fly further on a single oxygen refill or save space and weight with a smaller tank. It also makes it more feasible to enjoy the advantages of oxygen while flying below the altitudes where oxygen is mandated-- that can mean fewer headaches, increased alertness, and feeling less exhausted when you reach your destination. Your actual oxygen usage will be determined by your breathing rate and physiological needs at altitude. The programmability of the  MH EDS means that, unlike constant-flow oxygen systems, you can “set it and forget it”. By automatically detecting your pressure altitude, the MH EDS can be set to start providing oxygen immediately or at a specified altitude and will automatically adjust the oxygen flow as your altitude changes. When you're flying, don't you have more important things to do than adjust your oxygen flow during altitude changes?



EDS-O2D2-2Gd-unit 96dpiEDS-O2D2-2Ge-unit 96dpi



Note: Our EDS O2D2-2G and O2D1-2G are portable systems designed and calibrated to be used with our regulators (~15 psig. dynamic to 25 MAX. psig. static). However, if you wish to operate from the outlets of a built-in system, we offer the EDS-STR stabilizing regulator. This will allow our portable EDS systems to operate with built-in systems that supply up to 90 psig. to the outlets in the aircraft.

The MH EDS O2D2-2G Pulse Demand Oxygen Delivery System is the only single unit, portable, two-place oxygen system currently available for general aviation. A variety of options allow you, the pilot, to customize a system to your specific needs. The O2D2-2G kit comes with (3) AA batteries, 2 standard cannulas, 2 flare tip cannulas, and 2 face masks all in a handy carry bag. Various configurations of our complete O2D2-2G systems are listed below. Call for more options.


pdf_available

If you already have a Cylinder and MH Regulator, you can order just the O2D2-2G unit kit.





O2D2-Bags-crop-96dpi


Description: EDS O2D2-2G Kit
MH Item #: 00EDS-2200-00


Product
00EDS-2200-00
O2D2-2G-Kit
Price/Unit
895.00 USD
Qty



Also available the O2D2-2G EPS External Power Supply to power your unit from your airplane's power supply. In addition, we offer the In-Line Regulator pressure reducing and stabilizing regulator to allow the use of regulators up to 90 psig output.







O2D2-2G Basic Kit with Regulator

Description: O2D2-2G kit with your choice of MH-Regulator. You supply the cylinder.

Note: 540 regulators are US standard. DIN-477 regulators fit European style cylinder valves.


Description: EDS-O2D2-2G with XCR-540 regulator.
O2D2-2G-with-cannula-96dpiREG-1032XCRMH Item #: 00EDS-2152-00

Product
00EDS-2152-00
O2D2-X-XCR
Price/Unit
1,040.00 USD
Qty








Description: EDS-O2D2-2G with XCR-540 regulator with gauge.
O2D2-2G-with-cannula-96dpiREG-1030XCRMH Item #: 00EDS-2152-01

Product
00EDS-2152-01
O2D2-X-XCR-G
Price/Unit
1,079.00 USD
Qty








Description: EDS-O2D2-2G with XCR-DIN-477 (Euro Inlet) regulator with gauge.

O2D2-2G-with-cannula-96dpiREG-1036XCRGMH Item #: 00EDS-2152-03

Product
00EDS-2152-03
O2D2-XCR-DIN-G
Price/Unit
1,095.00 USD
Qty









 Description: EDS-O2D2-2G with FPR-540 regulator.

O2D2-2G-with-cannula-96dpiREG-1018FPRMH Item #: 00EDS-2154-00

Product
00EDS-2154-00
O2D2-X-FPR
Price/Unit
1,175.00 USD
Qty








Description: EDS-O2D2-2G with FPR-540 regulator with gauge.

O2D2-2G-with-cannula-96dpiREG-1016FPRGMH Item #: 00EDS-2154-01

Product
00EDS-2154-01
02D2-X-FPR-G
Price/Unit
1,195.00 USD
Qty










Description: EDS-O2D2-2G with FPR-DIN-477 regulator with gauge.
O2D2-2G-with-cannula-96dpiREG-1024FPRGMH Item #: 00EDS-2154-03

Product
00EDS-2154-03
O2D2-X-FPR-DIN-G
Price/Unit
1,215.00 USD
Qty













EDS-O2D2-2G Kits to work with Factory Built in Oxygen Systems,
using our STR In-line Regulators.

Many factory built in systems operate with regulated pressures that are not compatible (to high) with
Mountain Highs EDS-Pulse Demand™ System. Our system requires aproximently 20psi of regulated
pressure.
The Mountain High STR In-line Stabilizing Regulator allows you to operate Our EDS units from an oxygen
source with pressure up to 150psi, such as an Aircraft with a built-in oxygen system.
The EDS Pulse Demand™ systems can be ordered with the most common OEM type connectors for direct
"Plug-n-Fly" operations.


Inline-OH-0web

REG-1048-05

BNC Oxygen connectors to work with almost any type of built-in aircraft oxygen systems.

BNC-SET






BNC-SCOTT

BNC-SC01-100 connector fits most Beechcraft, Mooney and Piper with built-in oxygen systems.

BNC-PB-566
Fits most Cessna single engine prior to 1980.
Fits most Cessna twin engine prior to 1970.

BNC-PB-750
Fits most late model Cessna singles 1980 on.
Fits most late model Cessna twins 1970 on.
Also fits Piper Matrix.







O2D2-2G-with-cannula-96dpi
REG-1048-00Description: O2D2-2G-X-STR (no connector)

 Note: If using your own connector make sure there is no restrictor installed.

MH Item #: 00EDS-2150-00

Product
00EDS-2150-00
O2D2-X-STR(No-Connector)
Price/Unit
1,075.00 USD
Qty






O2D2-2G-with-cannula-96dpiREG1048-01Description: O2D2-2G-X-STR-BNC (Scott)

MH Item #: 00EDS-2150-01

Product
00EDS-2150-01
O2D2-X-STR-SCT
Price/Unit
1,095.00 USD
Qty







O2D2-2G-with-cannula-96dpiREG-1048-02Description: O2D2-2G-X-STR-BNC (PB750)

MH Item #: 00EDS-2150-02

Product
00EDS-2150-02
O2D2-XSTR-PB750
Price/Unit
1,095.00 USD
Qty






O2D2-2G-with-cannula-96dpiREG-1048-03Description: O2D2-2G-X-STR-BNC (PB566)

MH Item #: 00EDS-2150-03

Product
00EDS-2150-03
O2D2-X-STR-PB566
Price/Unit
1,095.00 USD
Qty






O2D2-2G-with-cannula-96dpiREG-1048-04Description: O2D2-2G-X-STR-CPC (Cirrus-Cessna-Columbia)

MH Item #: 00EDS-2150-04

Product
00EDS-2150-04
02D2-X-STR-CPC(CIRRUS/CESSNA/COLUMBIA)
Price/Unit
1,095.00 USD
Qty










O2D2-2G Kits with Aluminum Cylinders

 O2D2-2GKit-b96dpipdf_available



O2D2-2G Kit Shown with Cylinder and Full Pack


 Description: EDS-O2D2-2G with AL-180 Aluminum cylinder and XCR-540 regulator.

O2D2-2G-with-cannula-96dpiAL-180REG-1032XCR









 AL-180 Holster
MH Item #: 00EDS-2053-02
with Holster Pack
Product
00EDS-2053-02
O2D2-180-2P-H
Price/Unit
1,165.00 USD
Qty




MH
Item #: 00EDS-2054-02
  with Full Pack

Product
00EDS-2054-02
O2D2-180-2P-F
Price/Unit
1,210.00 USD
Qty






Description: EDS-O2D2-2G with AL-248 Aluminum cylinder and XCR-540 regulator.
O2D2-2G-with-cannula-96dpiAL-248REG-1032XCRMH Item #: 00EDS-2058-02
with Full Pack

Product
00EDS-2058-02
O2D2-248-2P-F
Price/Unit
1,250.00 USD
Qty








Description: EDS-O2D2-2G with AL-415 Aluminum cylinder and XCR-540 regulator.
O2D2-2G-with-cannula-96dpiAL-415REG-1032XCRMH Item #: 00EDS-2060-02
 with Full Pack

Product
00EDS-2060-02
O2D2-415-2P-F
Price/Unit
1,255.00 USD
Qty








Description: (2) EDS-O2D2-2G units with AL-415 Aluminum cylinder, FPR-540 regulator.
O2D2-2G-with-cannula-96dpiO2D2-2G-with-cannula-96dpiAL-415REG-1018FPRMH Item #: 00EDS-2060-04
 with Full Pack

Product
00EDS-2060-04
O2D2-415-4P-F
Price/Unit
2,195.00 USD
Qty










Description: EDS-O2D2-2G with AL-415 Aluminum cylinder and XCR-DIN-477 regulator.
O2D2-2G-with-cannula-96dpiAL-415REG-1036XCRGMH Item #: 00EDS-2060-D2
 with Full Pack

Product
00EDS-2060-D2
O2D2-415-2P-F-DIN
Price/Unit
1,315.00 USD
Qty














Description: EDS-O2D2-2G with AL-647 Aluminum cylinder and XCR-540 regulator.
O2D2-2G-with-cannula-96dpiAL-647REG-1032XCRMH Item #: 00EDS-2062-02
with Full Pack

Product
00EDS-2062-02
O2D2-647-2P-F
Price/Unit
1,325.00 USD
Qty









Description: (2) EDS-O2D2-2G units with AL-647 Aluminum cylinder, FPR-540 regulator.
O2D2-2G-with-cannula-96dpiO2D2-2G-with-cannula-96dpiAL-647REG-1018FPRMH Item #: 00EDS-2062-04
 with full pack

Product
00EDS-2062-04
O2D2-647-4P-F
Price/Unit
2,270.00 USD
Qty









 Description: EDS-O2D2-2G with AL-647 Aluminum cylinder and XCR-DIN-477 regulator.

O2D2-2G-with-cannula-96dpiAL-647REG-1036XCRGMH Item #: 00EDS-2062-D2
 with Full Pack

Product
00EDS-2062-D2
O2D2-647-2P DIN
Price/Unit
1,385.00 USD
Qty








Description: EDS-O2D2-2G with AL-682 Aluminum cylinder and XCR-540 regulator.
O2D2-2G-with-cannula-96dpiAL-682REG-1032XCRMH Item #: 00EDS-2064-02
 with Full Pack

Product
00EDS-2064-02
O2D2-682-2P-F
Price/Unit
1,265.00 USD
Qty










Description: (2) EDS-O2D2-2G with AL-682 Aluminum cylinder, FPR-540 regulator.
O2D2-2G-with-cannula-96dpiO2D2-2G-with-cannula-96dpiAL-682REG-1018FPRMH Item #: 00EDS-2064-04
 with Full Pack

Product
00EDS-2064-04
O2D2-682-4P-F
Price/Unit
2,215.00 USD
Qty









Description: EDS-O2D2-2G with AL-682 Aluminum cylinder and XCR-DIN-477 regulator.

O2D2-2G-with-cannula-96dpiAL-682REG-1036XCRGMH Item #: 00EDS-2064-D2
 with Full Pack

Product
00EDS-2064-D2
O2D2-682-2P-F-DIN
Price/Unit
1,325.00 USD
Qty












O2D2-2G Kits with Composite Cylinders

 Description: EDS-O2D2-2G with KF-011 Kevlar cylinder and XCR-540 regulator.

O2D2-2G-with-cannula-96dpiKF-011REG-1032XCRMH Item #: 00EDS-2002-02
 with Full Pack

Product
00EDS-2002-02
O2D2-011-2P-F
Price/Unit
1,669.00 USD
Qty







Description: EDS-O2D2-2G with KF-011 Kevlar cylinder and XCR-DIN-477 regulator.

O2D2-2G-with-cannula-96dpiKF-011REG-1036XCRGMH Item #: 00EDS-2002-D2
 with Full Pack

Product
00EDS-2002-D2
O2D2-011-2P-DIN-477-F
Price/Unit
1,735.00 USD
Qty








Description: EDS-O2D2-2G with CFFC-022 carbon fiber cylinder, XCR-540 regulator.
O2D2-2G-with-cannula-96dpiCFFC-022REG-1032XCRMH Item #: 00EDS-2004-02
  with Full Pack

Product
00EDS-2004-02
O2D2-022-2P-F
Price/Unit
2,195.00 USD
Qty

Product
00EDS-2004-D2
02D2-022-2P-F-DIN
Price/Unit
2,280.00 USD
Qty








Description: (2) EDS-O2D2-2G with CFFC-022 carbon fiber cylinder, FPR-540 regulator.

O2D2-2G-with-cannula-96dpiO2D2-2G-with-cannula-96dpiCFFC-022REG-1018FPRMH Item #: 00EDS-2004-04
 with Full Pack

Product
00EDS-2004-04
O2D2-022-4P-F
Price/Unit
3,095.00 USD
Qty








Description: EDS-O2D2-2G with CFFC-048 carbon fiber cylinder and XCR-540 regulator.



O2D2-2G-with-cannula-96dpiCFFC-048REG-1032XCRMH Item #: 00EDS-2014-02
 USD with Full Pack





Product
00EDS-2014-02
O2D2-048-2P-F
Price/Unit
1,915.00 USD
Qty




Description: (2) EDS-O2D2-2G with CFFC-048 carbon fiber cylinder and FPR-540 regulator.



O2D2-2G-with-cannula-96dpiO2D2-2G-with-cannula-96dpiCFFC-048REG-1018FPRMH Item #: 00EDS-2014-04
 with Full Pack





Product
00EDS-2014-04
O2D2-048-4P-F
Price/Unit
2,855.00 USD
Qty




Description: EDS-O2D2-2G and CFF-480 Silica cylinder, XCR-540 regulator.

O2D2-2G-with-cannula-96dpiCFF-480REG-1032XCRMH Item #: 00EDS-2084-02
 with Full Pack

Product
00EDS-2084-02
O2D2-480-2P-F
Price/Unit
1,895.00 USD
Qty








 Description: (2) EDS-O2D2-2G with CFF-480 Silica cylinder, FPR-540 regulator.

O2D2-2G-with-cannula-96dpiO2D2-2G-with-cannula-96dpiCFF-480REG-1018FPRMH Item #: 00EDS-2084-04
 with Full Pack

Product
00EDS-2084-04
O2D2-480-4P-F
Price/Unit
2,795.00 USD
Qty






Description: EDS-O2D2-2G, CFF-480 Silica cylinder, XCR DIN-477 regulator.

O2D2-2G-with-cannula-96dpiCFF-480REG-1036XCRGMH Item #: 00EDS-2084-D2
 with Full Pack

Product
00EDS-2084-D2
O2D2-480-2P-F-DIN
Price/Unit
1,940.00 USD
Qty












Attachments:
FileDescriptionFile size
Download this file (EDS-O2D2-2G Manual (5MD20-0002-00$b).pdf)EDS-O2D2-2G Manual06/16/177315 Kb
